產品型號:UP22W
產品代碼:
產品價格:3500
折 扣 率: 0
最后更新:2014-07-11
關 注 度:3012
生產企業:深圳市優筆觸控科技有限公司
|
|
|
與企業聯系時請告知該信息來自教育裝備網! |
|
|
產品詳細介紹顯示屏描述/Panel Description 顯示屏尺寸/Panel Size 21.5Inch 顯示屏類型/Panel Type TFT LCD 屏幕比率/Display Ratio 16:9 AA區/Active Area 476.64X268.11mm 像素/Pixels 1920*1080 點距/Pixel Pitch 0.248mmX0.248mm 亮度/White Luminance(TYP) 250cd/m2 顏色/Color 16.7M Colors 響應時間/Response Time 5ms 可視角度/Viewing Angle Horizontal 170°,Vertical160°@CR≥10 觸控描述/Touch Description 觸控技術/Touch Technology 電磁感應無線無源 Electromagnetic Resonance Without Battery 分辨率/Resolution 2048LPI 壓感/Pressure Level 2048 報點率/Report Rate 200pps 精準度/Accuracy ±0.5mm(Center),±2mm(Edge) 傾斜角度/Tilt Angle ±45°from Vertical 感應高度/Sensor Height 5-15mm 接口/Interface USB2.0 操作系統/Support OS WinXP、Vista、Win7 、Win8 and Mac OS 筆描述/Pen Description 類型/Type Wireless Pen without Battery 按鍵/Press Key Upper Key(Mouse Right-Key Function) Lower Key(User Defined) 筆尖/Pen Tip Switch Freely 重量/Weight 20g 電源/Power Supply 電源類型/Power Supply Type External DC Power Adapter 輸入電壓/Power 110V-220V 輸出電壓電流/Output Voltage/Current 12V/3A 功耗/Consumption 30W 接口/Interface 電源接口/DC Jack DC Jack*1 觸控接口/Touch Interface USB2.0*1 輸入接口/Video Input VGA IN*1,HDMI*1,DVI*1 操作控制/Operation Control 菜單語言/OSD Language Chinese/English,9 Languages 按鍵/Press Keys Power On/Off、Up/Down、Menu、Auto 其他/Others 外形尺寸/Dimension 531(L)*318(W)*40(H)mm 凈重/Net Weight 3.8KG 毛重/Gross Weight 4.3KG 工作溫度/Working Temperature 0~50℃ 工作濕度/Working Humidity 5~90% 儲存溫度/Storage Temperature -20~60℃ 儲存濕度/Storage Humidity 5~90% |
|
會員級別:免費會員 |
加入時間:2014-07-11
|
|
|
